Description
Wood carving machine CNC Router
Working area 1300*2500*210
Platform size 1480*3100mm
Resolutions ±0.05mm
System resolutions ±0.001
Repeat positioning accuracy 0.03mm
Table structure Vacuum adsorption
Shaft drive mode XY axis rack drive Z axis screw drive
Shaft power mode Panasonic servo motor ( Z axis with brake functions )
Max traveling speed 5000mm/min
Max working speed 20000mm/min
Spindle power 4.5kw 6kw
Spindle speed 0-18000r/min
Run command G code
Vacuum pump 7.5 kw
Voltage AXC380/3HP/50HZ
Weight 2000kg
