Description
https://www.ideal.de/en/cutting-machines/guillotines/4850
IDEAL 4850
Guillotine Cutter:
Power guillotine with automatic clamp and 475 mm cutting length.
The hinged safety guard has to be closed to unlock the blade lever for the cutting process.
The calibrated hand crank and the measuring tape on the side lay ensure the exact positioning of the backgauge.
A cut can be executed conveniently by means of the patented EASY-CUT blade activating bars, which guarantee a safe two-hand operation.
The optical cutting line indicator with especially bright and durable LEDs guarantees easy alignment of cutting marks for precise cuts.
Safe and convenient blade change without removing covers. Blade changing device covers cutting edge of blade to protect the operator.
The practical hook-in tool holder is placed on the back table and keeps all necessary tools for blade change and service jobs within reach.
Tech Specs:
- Voltage – 230 V / 50 Hz / 1
- Power – 1.42 kW
- Dimensions (HxWxD): 1296x762x1053 mm
- Weight: 225 kg
- Maximum cutting speed: 5 cycles/min
- Cutting height: 80 mm
- Narrow cut: 30 mm
- Cutting length: 475 mm
- Table depth: 458 mm
Power supply: 220V/60Hz/3~
Cutting length: 720 mm
Cutting height: 80 mm
Table depth: 720 mm
Sound level EN 13023: 72 dB (A)
Weight: 613 kg
