Description
DE400E0
complete with C13 Sound Attenuated
Enclosures 50/60 Hz
Features
Robust/Highly Corrosion Resistant Construction
• Factory installed on integral fuel tank base
• Environmentally friendly, polyester powder baked paint
• 1.6 mm (0.063 in) galvanized steel
• All round overhanging base to protect enclosure
• High-grade engineering thermoplastic corner posts for protection • Integral lifting frame
• Compression door latches giving solid door seal
• Zinc plated or black coated stainless steel fasteners
• Internally mounted super critical exhaust silencing system
Excellent Access
• Large cable entry area for installation ease
• Accommodates rear mounted breaker and control panel
• Double doors on both sides
• Vertically hinged doors with solid bar door stays to hold doors open at 135° rotation • Lube oil and coolant drains pipes to exterior of enclosure and terminated drain valves • Radiator fill cover
Security and Safety
• Lockable access doors which give full access to control panel and breaker • Cooling fan and battery charging alternator fully guarded
• Fuel fill, oil fill and battery can only be reached via lockable access
• Externally mounted emergency stop button
• Designed for spreader-bar lifting to ensure safety • Control panel viewing window
• Stub-up area is rodent proof
Options
• Caterpillar yellow or white paint
• Integral dual wall fuel tank base for total fluid containment (fuel, oil and coolant)
DE150E0
Frequency (Hz): 50
Power (kVa/kw): 150/120
Voltage (V): 50
